    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Ask Lasest Price
    Brand Name : Nage
    Certification : CE/SGS
    Supply Ability : 50 Set/Sets per Month
    Price : $24,000.00
    • Product Details
    • Company Profile

    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    10 Chutes High Output Intelligent CCD Grain Color Sorter


    model6SXM-6406SXM-4486SXM-5126SXM-2566SXM-384
    chutes, No.640448512256384
    product output8.0-185.0-126.0-143.0-6.54.0-10.0
    sorting accuracy99.999.999.999.999.9
    optimized carryover8:18:18:18:18:1
    weight(kg)1650141015908701230
    minium identification0.030.030.030.030.03
    power (kw)5.544.52.53.5
    power supply (v/hz)AC220/50AC220/50AC220/50AC220/50AC220/50
    Dimension (l*w*h)mm3846*1587*19683060*1536*16903367*1536*16902085*1536*16902715*1536*1690

    Product Description
    NAGE intelligent CCD rice color sorter is a chute type precise selection device.Among them,the front and rear views can be equipped with visible sight mirror using the latest CCD color sensor,color selection customized lens,high-speed FPGA data processor,high-speed electromagnetic actuator and easy-to-operate human -computer interface with touch function. it is a high -tech product integrating light, machine, electricity and gas.
    Technical Parameter
    MODEL
    6SXM-640
    Executing Unit (MM)
    640
    Product Output(T/H)
    8.0-18
    Sorting Accuracy(%)
    ≥99.9
    Optimized Carryover(Bad:Good)
    ≥8:1
    Weight(KG)
    1650
    Power(KW)
    5.5
    Power Supply(V/HZ)
    AC220/50
    Dimension (L*W*H)mm
    3846*1587*1968
    Examples of sorting
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    Detailed Images
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Lens and image acquisition
    CCD true color sorting technology, color high-definition recognition, high speed sorting, recognition more accurate.
    5400 pixels high precision professional lens ensures image clarity and accuracy. The highest resolution is as high as 0.02 mm-2, which can accurately identify small defects and spots in the material.
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Image processing algorithm
    Powerful image processing algorithm, using color selection and shape selection combined algorithm, can accurately identify the color and shape of materials.
    Photo capture technology and high-definition imaging technology, materials and colors can be defined color selection.
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Solenoid value
    Using high-quality solenoid valve, high frequency and long life. While ensuring the output, the take-out ratio is reduced.
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    LED light source
    The newly designed LED light source has the advantages of high brightness, long life, good heat dissipation, and can be used for color sorting of various materials and colors.
    Different materials do not need to replace the light source.
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Feed tank
    Special anodizing process,large output and uniform cutting. Waterfall plate and narrow chute channel to meet the color selection of different materials.
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Interface Powerful software operating platform
    Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
    Packing&Shipping
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror

    Our services

    Before sale
    We will provide detailed solutions for your special requirement and help you know more about our color sorter.
    After sale services
    1.We provide customer with one year free repair and maintenance for complete machine.
    2.We also provide lifetime professional training and technical guidance service.
    Our company
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    10 Chutes High Output Grain Color Sorter Equipped With Visible Sight Mirror
    FAQ
    1.Q:How about engineers service oversea?
    A:Engineers available to service machinery overseas.

    2.Q:How to use the machine?
    A:We will supply customer the installation catalog or video online.We will ask our engineer to teach you, how to use when he go to your country to debug the machine.

    3.Q:How about the sample machines for testing?
    A:Sample sending for testing is welcomed.Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to discard).We send our video to you.

    4.Q:How about the guarantee period?
    A:One year.

    5.Q:Will you accept L/C as payment?
    A:L/C ,T/T is OK.Alibaba Trade Assurance is your best choice.

    6.Q:Do you have any other spare parts for the customer?
    A:Yes,we will supply you some spare parts.

    7.Q:Which machine will work together with our color sorter which you can supply?
    A:Air compressor,Air tank,Air filters,Air dryer,Light sources,Cleaning brushes,etc
